OSBiz V3 X3R/X5R Basic Mainboard OCCMBR L30251-U600-G684

OSBiz V3 X3R/X5R Basic Mainboard OCCMBR L30251-U600-G684

NEW Item
Manufacturer Part Number: L30251-U600-G684

OSBiz V3 X3R/X5R Basic Mainboard OCCMBR

• 2 Gigabyte LAN ports (customer LAN, service)
• 1 Gigabyte (WAN connection (Internet direct))
• 8 UP0/E subscribers via RJ connector on the front panel
• 4 analog subscribers (a/b) via RJ connector on the front panel
• 1 USB 2.0 connection (service)
• 1 USB 2.0 connection (USB storage medium)
• 2 USB 3.0 connector (USB storage medium)
• 1 jack socket 3.5mm for music on hold / announcements via analog audio devices
• 1 connector strip (internal) for M.2 SATA SSD memory card
• 1 connector strip (internal) for optional M.2 NVMe SSD memory card
• 1 header (internal) for optional Voice Channel Module (OCCB)
• 1 connector block (internal) for optional actuator/sensor module (STRBR)
• 1 connector strip (internal) for optional clock module (CMAe)

Scope of delivery
S30810-K2965-R100 OCCMBR Mainboard X3 X5

Note text Scope of delivery
Without System SW. This mainboard can only be used with System SW on M.2 SATA SSD card.
The System SW on M.2 SATA SSD card is not included and must be ordered separately: L30251-U600-G668.
