OSBiz V3 X3W/X5W Basic Mainboard OCCMB L30251-U600-G682
NEW Item
Manufacturer Part Number: L30251-U600-G682
- 2 Gigabyte LAN ports (customer LAN, service)
- 1 Gigabyte (WAN connection (Internet direct))
- 8 UP0/E subscribers via internal connector strip
- 4 analog subscribers (a/b) via internal connector strip
- 1 USB 2.0 port (service)
- 1 USB 2.0 port (USB storage medium)
- 2 USB 3.0 connection (USB storage medium)
- 1 jack socket 3.5mm for music on hold / announcements via analog audio devices
- 1 connector strip (internal) for M.2 SATA SSD memory card
- 1 connector strip (internal) for optional M.2 NVMe SSD memory card
- 1 header (internal) for optional Voice Channel Module (OCCB)
- 1 connector block (internal) for optional actuator/sensor module (STRB)
- 1 connector strip (internal) for optional clock module (CMAe)
Scope of delivery
S30810-K2965-W100 OCCMB Mainboard X3 X5
Note text Scope of delivery
Without System SW. This mainboard can only be used with System SW on M.2 SATA SSD card.
The System SW on M.2 SATA SSD card is not included and must be ordered separately: L30251-U600-G668.
