Neat Board - 65 Collaboration and touch screen for Zoom & Teams NEATBOARD-SE
NEW Item
Manufacturer Part Number: NEATBOARD-SE
Creativity across the Board.
Neat Board is the complete meeting room package in a simple and elegant all-in-one device. With its immersive 65-inch multi-touch screen, powerful audio system and versatile wide-angle camera, Neat Board gives you a collaboration experience beyond video meetings and wireless content sharing by enabling annotations and whiteboarding.
Simple set-up.
Designed to provide everything you need in your meeting room today, Neat Board gives you the freedom and flexibility to collaborate however you want in the future. It's also easy to set up, having just one cable and a choice of either a floor stand with optional wheels, wall mount or table stand.
Just works.
Neat Board responds to your presence and automatically wakes up the moment you walk into the room. With just one tap, you can wirelessly share your screen, start a meeting or mark something up. The large multi-touch screen is perfect for taking notes, organizing thoughts and providing quick visual feedback, whether people are right there in the room or on video.
Make your mark.
Neat Board comes with a pair of Neat Markers that attach magnetically to the Neat Marker holder, which also serves as cable management. Neat Marker delivers just the right amount of friction for whiteboarding and markup and is passive, so you don't need to set it up or charge it.
No idea left behind.
With our partners at Zoom, we’re enhancing the whiteboard experience with simple powerful tools that match the way you work. The infinite canvas will provide your team with the space you need to brainstorm, organize and restructure - even when physically apart. Share the output and continue where you left off in the next meeting.
- 65″ 4K multi-touch LED
- 120° FOV Wide angle camera
- 12 MP Capture resolution
- 4x Digital zoom (8x optional)
- 5 mic array
- Opposing drivers
- Wide angle tweeter
- Wi-Fi
- Air quality sensors
Neat Board is the complete Zoom Rooms or Microsoft Teams package in a simple and elegant all-in-one device.
* Feature not yet supported by Microsoft Teams
** Needs to be purchased from Zoom or Microsoft
General
- 65-inch capacitive multi-touch LED screen
- Ultra HD 4K (3840 x 2160 screen resolution)
- 16:9 aspect ratio
- Anti-glare and anti-fingerprint coating
- Camera LED
- System LED
- Ambient light sensor
- 2 × Neat Marker (passive)
- Table stand
- Floor stand (optional)
- Wall mount (optional)
- Neat Pad controller (optional)
- Neat Pad scheduling display (optional)
- BYOD mode (USB passthrough)
- Native support for Zoom Rooms
- Native support for Microsoft Teams Rooms on Android
- Sensors for temperature, humidity, CO2 and VOC (*)
Audio
- Speaker box for maximum tonal range with minimal distortion
- Opposing drivers for vibration cancellation
- Dedicated wide-angle ultrasonic tweeter
- 3 sensor mics
- 5 beamforming microphones angled in an end-fire array
- Hardware-accelerated audio processing (NAP)
- Echo cancellation
- Noise suppression
- Automatic gain control
- Dereverberation
Video
- 4x digital zoom (optional 8x digital zoom)
- Fixed lens, infinite focus
- F-value: 2.8
- 4056*3040 (12 MP) capture resolution
- 120 degrees horizontal field of view
- Automatic people framing
- Hardware accelerated video encode and decode
- Distortion correction
- Noise reduction
- Chromatic aberration correction
- Automatic white balance and color correction
Electrical and environmental requirements
- 100-240V ~ 50/60Hz 2.5A
- Ambient operating temperature: 32° to 95° F (0° - 35° C)
- Storage temperature: -4° to 140° F (-20° to 60° C)
- Relative humidity: 10% to 90%
- Built-in power supply
Power consumption
- Idle: 145W
- Idle screen off: 17,5W
- In call: 152W
Networking & ports
- WiFi
- Bluetooth for Proximity Join in Microsoft Teams
- AC Power (internal power supply)
- Ethernet
- USB-C for BYOD mode (USB passthrough)
- HDMI-in for sharing in Zoom or Microsoft Teams (1080p)
- HDMI-in (4K)
Size & weight
Table stand
- Width: 58.1 inches (1476 mm)
- Height: 39.5 inches (1003 mm)
- Depth: 13.8 inches (350 mm)
- Weight: 102.6 pounds (46.5 kg)
Wall mount (optional)
- Width: 58.1 inches (1476 mm)
- Height: 37 inches (939 mm)
- Depth: 4.1 inches (105 mm)
- Weight: 111.6 pounds (50.6 kg)
Floor stand (optional)
- Width: 58.1 inches (1476 mm)
- Height: 71.65 inches (1820 mm)
- Depth: 34.98 inches (888 mm)
- Weight: 124.6 pounds (56.5 kg)
In the box
Neat Board
- 2 × Neat Marker
- Neat Marker holder
- 2.5 mm hex wrench
- Power cord (9.9 feet / 3 meters)
- Ethernet cable (16.4 feet / 5 meters)
Table stand
- 2 × M6 screw (2.5 inches / 65 mm)
- 5 mm hex wrench
What you need
- Internet connection
- License for Zoom Rooms or Microsoft Teams (**)
Optional extras
Wall mount
- 2 × M6 screw (0.8 inches / 20 mm)
- 5 mm hex wrench
Floor stand
- 2 × M6 screw (2.5 inches / 65 mm)
- 12 × M4 screw (0.3 inches / 8 mm)
- 5 mm hex wrench
- 3 mm hex wrench
- 4 × wheels
- Power cord (14.8 feet / 4.5 meters)
Neat Pad
- 2 × Ethernet cable (9.8 feet / 3 meters + 16.4 feet / 5 meters)
- PoE power adapter
- Mount adapter, side mount and wall mount
- 4 × M4 screw (0.39 inches / 10 mm) for the wall mount
- 3 × M4 screw (0.26 inches / 6.7 mm) for the side mount
- 2 mm hex wrench
- 2.5 mm hex wrench
Box weights and dimensions
Neat Board with table stand
Wall mount
Floor stand
